主要用途
適用于將多種植物藥的根、莖、葉、草、皮等切制成所需規格的段(節),以供提取和粉碎用。
Main uses
Suitable to cut herb roots、stems、grass、 fruits, barks into pieces ready for future extracting and grinding, as well as other pieces.
主要特點
切片厚度調整方便.獨特的壓輥機構及動、定刀剪 切機構工作可靠、高效,維修方便.符合GMP要求。
Main technical characteristics
The cut herb thickness can be adjusted easily, the unique structure of pressure roller and the combination of rolling knives and fixed knives make the machine work more smoothly, thus it can meet the requirements of GMP.
主要技術參數 Main technical parameter
型號 Type |
生產能力 Capacity (kg/h) |
藥口尺寸 herb inlet door size (mm) |
切制長度 the cut herb length (mm) |
電機功率 motor (KW) |
外形尺寸 dimension (mm) |
整機重量 weight (kg) |
QXG360 | 300-2000 | 240x45 | 4-20 | 7.5+4 | 2280x800x1428 | 1100 |
