主要用途
適用于植物藥塊狀及根、莖、葉類的物料清洗除塵。XY320型可用子教學演示。
Main uses
Suitable for washing herb blocks, stems、 leaves、grass and barks. This type can also be used for teaching presentation.
主要特點
使用高壓水沖洗,具有洗凈效果好、操作方便等優 點,符合GMP要求。
Main technical characteristics
The herb is washed by high pressure water, thus good washing result can be achieved. The machine is easy to control and maintain and can meet requirements of GMP.
主要技術參數 Main technical parameter
型號 Type |
生產能力 Capacity (kg/h) |
滾筒直徑 Rotating tank diameter (mm) |
電機功率 motor (KW) |
水壓 water pressure (MPa) |
外形尺寸 dimension (mm) |
整機重量 weight (kg) |
XY-320 | 80-120 | 320 | 0.55 | 0.3 | 1520x520x765 | 110 |
XY-500 | 140-500 | 500 | 1.1 | 0.3 | 1960x600x960 | 300 |
XY-720 | 200-750 | 720 | 1.1 | 0.3 | 2800x820x1300 | 500 |
XY-320 | 500-1200 | 900 | 1.5 | 0.3 | 3340x1040x1565 | 800 |
