主要用途
適用于根、莖、葉、草、皮類天然植物藥的飲片切制及其它行業類似物料的切制。
Main uses
Suitable to cut herb roots、stem、leaves、grass、barks and similar materials in other industries.
主要特點
采用可調間歇進給機構,設有楔輪正、反進料裝置,操作簡便、高效,運轉平穩,維修方便,符合GMP要求。
Main technical characteristics
The herb can be fed periodically. There are herb forward and reversion devices. Thus the herb material can be fed and taken out very easily. The machine is easy to operate and maintain, thus it can meet the requirements of GMP.
型號 Type |
生產能力 Capacity (kg/h) |
刀門尺寸 Inlet door size (mm) |
切制長度 cut herb length (mm) |
電機功率 motor (KW) |
外形尺寸 dimension (mm) |
整機重量 weight (kg) |
WQY240-2 | 80-600 | 240x54 | 1-15無級調整 | 3 | 1500x800x1200 | 800 |
WQY-300 | 100-800 | 300x56 | 1-15無級調整 | 3 | 1500x860x1200 | 850 |
