主要用途
適用子根、莖、葉、草、皮、藤、花類天然植物藥的飲片切制及其它行業類似物料的切制加工。
Main uses
suitable to cutthe herb roots、stems、barks and flowers.
主要特點
用聚胺脂輸送帶送料，連續進料.自適應壓緊，適合切制精制飲片，飲片破損率低、片形好，整機易清洗，操作方便、運轉平穩、維修方便，符合GMP要求.
Main technical characteristics
The polyurethane belt can feed the herb continuously, and the herb material is pressed automatically. Thus the machine is suitable to cut delicate herb pieces, the machine has the characteristics of low bad herb piece ratio and good herb piece shape. It can meet the requirements of GMP.
主要技術參數 Main technical parameter
型號
Type |
生產能力
Capacity
(kg/h) |
輸送帶寬庫
belt width
(mm) |
切制長度
cut herb
length
(mm) |
電機功率
motor
(KW) |
外形尺寸
dimension
(mm) |
整機重量
weight
(kg) |
|
QWZL300 |
40-300 |
300 |
0.7-60 |
1.5 |
1600x1050x1280 |
500 |
